Lenze MC3000 Series - Manual (Page 10)

6 13435743_EDBM301_v14 .0
HP
(kW)
INPUT
VOLTAGE MODEL H W D N P Q R S
5
(3 .7)
240 / 200 M3250 7 .88 7 .86 5 .94 5 .13 3 .95 1 .50 5 .88 1 .13
480 / 400 M3450 7 .50 6 .12 5 .12 3 .77 3 .30 1 .37 5 .50 0 .88
590 M3551 7 .88 7 .86 5 .94 5 .13 3 .95 1 .50 5 .88 1 .13
7 .5
(5 .5)
240 / 200 M3275 9 .38 7 .86 6 .84 3 .93 4 .19 2 .00 5 .88 1 .13
480 / 400 M3475 9 .38 7 .86 6 .25 5 .13 3 .95 1 .50 7 .38 1 .13
590 M3575 9 .38 7 .86 6 .25 5 .13 3 .95 1 .50 7 .38 1 .13
10
(7 .5)
240 / 200 M32100 11 .25 7 .86 6 .84 3 .93 4 .19 2 .00 7 .75 1 .38
480 / 400 M34100 9 .38 7 .86 6 .84 3 .93 4 .19 2 .00 5 .88 1 .13
590 M35100 9 .38 7 .86 7 .40 3 .93 4 .19 2 .00 5 .88 1 .13
15
(11)
240/200 M32150 12 .75 7 .86 6 .84 3 .93 4 .19 2 .00 9 .25 1 .38
480/400 M34150 11 .25 7 .86 6 .84 3 .93 4 .19 2 .00 7 .75 1 .38
590 M35150 12 .75 7 .86 6 .84 3 .93 4 .19 2 .00 9 .25 1 .38
20
(15)
240 / 200 M32200 12 .75 10 .26 7 .74 5 .13 5 .00 2 .50 9 .25 1 .38
480/400 M34200 12 .75 7 .86 6 .84 3 .93 4 .19 2 .00 9 .25 1 .38
590 M35200 12 .75 7 .86 7 .40 3 .93 4 .19 2 .00 9 .25 1 .38
25
(18 .5)
240 / 200 M32250 15 .75 10 .26 8 .35 5 .13 5 .00 2 .50 12 .25 1 .38
480/400 M34250 12 .75 10 .26 7 .74 5 .13 5 .00 2 .50 9 .25 1 .38
590 M35250 12 .75 10 .26 7 .74 5 .13 5 .00 2 .50 9 .25 1 .38
30
(22)
240 / 200 M32300 15 .75 10 .26 8 .35 5 .13 5 .00 2 .50 12 .25 1 .38
480/400 M34300 12 .75 10 .26 7 .74 5 .13 5 .00 2 .50 9 .25 1 .38
590 M35300 12 .75 10 .26 8 .25 5 .13 5 .00 2 .50 9 .25 1 .38
40
(30)
480/400 M34400 15 .75 10 .26 8 .35 5 .13 5 .00 2 .50 12 .25 1 .38
590 M35400 15 .75 10 .26 8 .35 5 .13 5 .00 2 .50 12 .25 1 .38
50
(37 .5)
480/400 M34500 19 .75 10 .26 8 .55 5 .13 5 .75 2 .50 16 .25 1 .75
590 M35500 19 .75 10 .26 8 .55 5 .13 5 .75 2 .50 16 .25 1 .75
60
(45)
480/400 M34600 19 .75 10 .26 8 .55 5 .13 5 .75 2 .50 16 .25 1 .75
590 M35600 19 .75 10 .26 8 .55 5 .13 5 .75 2 .50 16 .25 1 .75
DIMENSIONS - CHASSIS AND TYPE 1 ENCLOSED
(continued)
