13435743_EDBM301_v14 .0 11
M3500 SERIES RATINGS
MODEL
INPUT OUTPUT
(480/590 Vac, 50 - 60 Hz) (0 - 460/575 Vac)
MODEL
NUMBER 1
FOR MOTORS
RATED
INPUT
PHASE
NOMINAL
CURRENT 2
(AMPS)
POWER
(kVA)
NOMINAL
CURRENT
(AMPS)
POWER
(kVA)
HP kW
M3510 1 0 .75 3 1 .9 / 1 .9 1 .9 1 .6 / 1 .6 1 .6
M3520 2 1 .5 3 3 .3 / 3 .3 3 .4 2 .7 / 2 .7 2 .7
M3530 3 2 .2 3 4 .6 / 4 .6 4 .7 3 .9 / 3 .9 3 .9
M3550/51 5 3 .7 3 7 .1 / 7 .1 7 .3 6 .1 / 6 .1 6 .1
M3575 7 .5 5 .5 3 10 .5 / 10 .5 10 .7 9 .0 / 9 .0 8 .8
M35100 10 7 .5 3 12 .5 / 12 .5 12 .8 11 .0 / 11 .0 11 .0
M35150 15 11 3 19 .3 / 19 .3 19 .7 17 .0 / 17 .0 16 .9
M35200 20 15 3 25 / 25 25 .4 22 / 22 21 .5
M35250 25 18 .5 3 31 / 31 31 .2 27 / 27 26 .9
M35300 30 22 3 36 / 36 37 .1 32 / 32 31 .9
M35400 40 30 3 47 / 47 47 .5 41 / 41 40 .8
M35500 50 37 .5 3 59 / 59 60 .3 52 / 52 51 .8
M35600 60 45 3 71 / 71 72 .5 62 / 62 61 .7
1 Refer to Section 3 for model number breakdown .
2 Refer to Section 8 for recommended fuse type .
