13435743_EDBM301_v14 .0 37
16 PROGRAMMING THE MC3000 DRIVE
16 .1 PROGRAMMING THE PARAMETERS
The MC3000 keypad serves two purposes: operating the drive when in the LOCAL mode,
and programming the parameters for particular applications . The keypad is shown below,
along with the display that should appear when the drive is first powered up:
AUTO
LOCAL
STOP > 20.00 HZ
START
STOP ENTER
REMOTE
MAN
PROG
RUN
To program the drive, the PROGRAM mode must be entered by pressing the PROG/
RUN button . If the password protection is disabled, pressing the PROG/RUN button will
result in direct entry into the PROGRAM mode . If the password protection is enabled,
the PASSWORD prompt will appear when an attempt is made to enter the PROGRAM
mode . The PASSWORD prompt appears as follows:
PASSWORD 0000
CURSOR
To enter the password, use the UP and DOWN arrow keys to scroll to the password
value, and then press the ENTER key .
NOTE
The factory default password is 0019 .
