Lenze MC3000 Series - Manual (Page 14)

10 13435743_EDBM301_v14 .0
M3400 SERIES RATINGS
MODEL
INPUT OUTPUT
(400/480 Vac, 50 - 60 Hz) (0 - 400/460 Vac)
MODEL
NUMBER 1
FOR MOTORS
RATED
INPUT
PHASE
NOMINAL
CURRENT 2
(AMPS)
POWER
(kVA)
NOMINAL
CURRENT
(AMPS)
POWER
(kVA)
HP kW
M3410 1 0 .75 3 2 .8 / 2 .4 2 .0 2 .3 / 2 .0 1 .6
M3420 2 1 .5 3 4 .7 / 4 .1 3 .4 3 .9 / 3 .4 2 .7
M3430 3 2 .2 3 6 .6 / 5 .7 4 .7 5 .5 / 4 .8 3 .8
M3450 5 3 .7 3 10 .2 / 8 .9 7 .3 8 .7 / 7 .6 6 .1
M3475 7 .5 5 .5 3 14 .7 / 12 .8 10 .6 12 .6 / 11 .0 8 .8
M34100 10 7 .5 3 18 .3 / 15 .9 13 .2 16 .0 / 14 .0 11 .2
M34150 15 11 3 28 / 24 19 .8 24 / 21 16 .7
M34200 20 15 3 36 / 31 25 .3 31 / 27 21 .5
M34250 25 18 .5 3 44 / 38 31 .9 39 / 34 27 .1
M34300 30 22 3 52 / 45 37 .6 46 / 40 31 .9
M34400 40 30 3 68 / 59 49 .0 60 / 52 41 .4
M34500 50 37 .5 3 85 / 74 61 .5 75 / 65 51 .8
M34600 60 45 3 100 / 87 72 .3 88 / 77 61 .3
1 Refer to Section 3 for model number breakdown .
2 Refer to Section 8 for recommended fuse type .
