28 13435743_EDBM301_v14 .0
13 .2 .4 MC3000 DISPLAY IN AUXILIARY MODE
If the ENTER key is held down, the display will enter the auxiliary mode and cycle between
two displays: a CONTROL display that indicates the control source (LOCAL, REMOTE, or
SERIAL), AUTO or MANUAL mode, and the speed reference source, and a TIME display
that indicates total elapsed run time . When the ENTER key is released, the display will
return to the previous screen . Examples of the auxiliary mode displays are shown below:
CONTROL DISPLAY
LOCAL -- AUTO -- IDC
CONTROL
SOURCE
AUTO/MAN
MODE
SPEED
REFERENCE
SOURCE
TIME DISPLAY
TIME: 487.2 HRS
The table below shows the possible SPEED REFERENCE SOURCE indications for the
CONTROL display in the auxiliary mode:
SPEED REFERENCE SOURCE TABLE
DISPLAY DESCRIPTION
kEY kEYPAD - p and q keys .
VDC
0 - 10 VDC analog input at TB-5A (In PID mode, this indicates that
the SETPOINT reference is a 0-10 VDC signal) .
IDC
4 - 20 mA analog input at TB-5B (In PID mode, this indicates that
the SETPOINT reference is a 4-20 mA signal) .
SP#1 - SP#4 PRESET SPEED #1 - PRESET SPEED #4
MkB
MANUAL kEYBOARD - The p and q keys are used for speed
control . This occurs in PID mode when the drive is put into HAND
(open-loop) mode .
AkB
AUTO kEYBOARD - The p and q keys are used as the PID
SETPOINT reference . This occurs in PID mode when the drive is
put into AUTO (closed-loop) mode .
