8
13435743_EDBM301_v14 .0
HP
(kW)
INPUT
VOLTAGE
MODEL
H
W
D
N
P
Q
R
S
10
(7 .5)
240 / 200 M32100 13 .75 10 .26 8 .35 5 .13 5 .75 2 .00 11 .75 1 .38
480 / 400 M34100 11 .75 10 .26 8 .35 5 .13 5 .75 2 .00 9 .75 1 .13
590
M35100 11 .75 10 .26 8 .35 5 .13 5 .75 2 .00 9 .75 1 .13
15
(11)
240/200
M32150 15 .75 10 .26 8 .35 5 .13 5 .75 2 .00 13 .75 1 .38
480/400
M34150 13 .75 10 .26 8 .35 5 .13 5 .75 2 .00 11 .75 1 .38
590
M35150 13 .75 10 .26 8 .35 5 .13 5 .75 2 .00 11 .75 1 .38
20
(15)
240 / 200 M32200* 15 .75 10 .26 8 .35 5 .13 5 .75 2 .00 11 .75 1 .38
480/400
M34200 15 .75 10 .26 8 .35 5 .13 5 .75 2 .00 13 .75 1 .38
590
M35200 15 .75 10 .26 8 .35 5 .13 5 .75 2 .00 13 .75 1 .38
25
(18 .5)
240 / 200 M32250* 20 .25 10 .26 8 .35 5 .13 5 .75 2 .00 16 .25 1 .38
480/400 M34250* 15 .75 10 .26 8 .35 5 .13 5 .75 2 .00 11 .75 1 .38
590
M35250* 15 .75 10 .26 8 .35 5 .13 5 .75 2 .00 11 .75 1 .38
30
(22)
240 / 200 M32300* 20 .25 10 .26 8 .35 5 .13 5 .75 2 .00 16 .25 1 .38
480/400 M34300* 15 .75 10 .26 8 .35 5 .13 5 .75 2 .00 11 .75 1 .38
590
M35300* 15 .75 10 .26 8 .35 5 .13 5 .75 2 .00 11 .75 1 .38
40
(30)
480/400 M34400* 20 .25 10 .26 8 .35 5 .13 5 .75 2 .00 16 .25 1 .38
590
M35400* 20 .25 10 .26 8 .35 5 .13 5 .75 2 .00 16 .25 1 .38
50
(37 .5)
480/400 M34500* 21 .00 13 .72 8 .35 5 .13 6 .10 2 .00 16 .25 1 .38
590
M35500* 21 .00 13 .72 8 .35 5 .13 6 .10 2 .00 16 .25 1 .38
60
(45)
480/400 M34600* 21 .00 13 .72 8 .35 5 .13 6 .10 2 .00 16 .25 1 .38
590
M35600* 21 .00 13 .72 8 .35 5 .13 6 .10 2 .00 16 .25 1 .38
*Models available in NEMA 12 only
DIMENSIONS - TYPE 4, 4X, AND 12 ENCLOSED (continued)
