98 EDK82EV903 DE/EN/FR 5.1
Key for overview
Interfaces and displays
Position Description Function
 2 light−emitting diodes (red,
green) Status display ^ 183
‚ AIF interface
(automation interface) Slot for communication module
e. g. E82ZBC keypad
^ 165
ƒ FIF Iinterface
(f
i i f )
With cover for operation without function module ^ 162
(function interface)
or slot for function module
„ FIF II interface
(f
i i f )
With cover for operation without function module
(function interface)
or slot for function module
E82EV153K4B ... E82EV303K4B
(fold−out page on the left)
Scope of supply and connections
Position Description
0 8200 vector frequency inverter
1 Fixing bracket for standard mounting ^ 120
2 Blanking covers (2 pieces) for interfaces FIF I and FIF II ^ 162
3 EMC shield sheet with fixing screws for shielded control cables ^ 142
4 Cover with fixing screws
5 EMC shield sheet for the motor cable and for the incoming motor temperature monitoring cable ^ 146
6 Label (required for mounting in accordance with UL) ^ 119
T1, T2 PTC connection or thermal contact (NC contact) of the motor ^ 146
U, V, W, PE Motor connection ^ 146
L1, L2, L3, PE Mains connection ^ 143
+U
G
, −U
G
DC supply
X1.2 Terminal strip for connection of relay output K1 ^ 155
X1.3 Terminal strip for connection of relay output K2
X3.1 Terminal strip for connection of relay output K
SR
for "safe standstill" (only for variant Bx4x) ^ 157
E82EV453K4B ... E82EV553K4B
(fold−out page on the left)
Scope of supply and connections
Position Description
0 8200 vector frequency inverter
1 Fixing bracket for standard mounting ^ 126
2 Blanking covers (2 pieces) for interfaces FIF I and FIF II ^ 162
3 EMC shield sheet with fixing screws for shielded control cables ^ 142
4 Cover with fixing screws
5 Shield clamp and strain relief for the motor cable ^ 150
6 Strain relief for the protective earth cable of the motor and the incoming cable of the motor tempera-
ture monitoring with PTC thermistor (PTC) or thermal contact (NC contact)
7 Label (required for mounting in accordance with UL) ^ 119
T1, T2 PTC connection or thermal contact (NC contact) of the motor ^ 150
U, V, W, PE Motor connection ^ 150
L1, L2, L3, PE Mains connection ^ 147
+U
G
, −U
G
DC supply
X1.2 Terminal strip for connection of relay output K1 ^ 155
X1.3 Terminal strip for connection of relay output K2
X3.1 Terminal strip for connection of relay output K
SR
for "safe standstill" (only for variant Bx4x) ^ 157
