6 Extensions for automation
6.1 Modules
The frequency inverters are provided with 3 slots at the housing front:
ƒ The two lower slots (FIF I and FIF II interface) serve to connect an I/O module or a bus
function module.
– An I/O function module (standard I/O or application I/O) expands the controller by
control terminals for analog or digital inputs/outputs.
– Via a bus function module (e.g. PROFIBUS−DP PT or CAN PT) you connect the
controller to a fieldbus.
– A bus function module with control terminals (e.g. PROFIBUS−I/O, CAN−IO PT) is a
combination of the above−mentioned function modules.
ƒ You can connect an operating module or a communication module to the upper slot
(AIF interface).
– Via the operating module you parameterise the controller according to its
application, read out its status and diagnose errors.
– Via a communication module you connect the controller to a PC or to a fieldbus.
{
Danger!
ƒ The pins of the FIF interface have a basic insulation (single−insulating
distance).
ƒ Protection against contact − in the event of a defective insulating distance −
can only be ensured by external measures, e.g. double insulation.
)
Note!
Information on how to wire and use the modules can be found in the
corresponding mounting instructions and communication manuals.
Possible combinations
,
