Lenze E82EV 8200 vector 15kW-90kW - Manual (Page 138)

Electrical installation
Important notes
5
l
138 EDK82EV903 DE/EN/FR 5.1
5 Electrical installation
5.1 Important notes
{
Danger!
Dangerous electrical voltage
Terminals can carry dangerous electrical voltage − also if the motor is stopped
or after the mains is switched off!
Possible consequences:
ƒ Death or severe injuries when touching live terminals.
Protective measures:
Before all operations on the controller
ƒ Switch off the mains voltage and wait for at least 3 minutes.
ƒ Check whether terminals are isolated from supply, since
– the power terminals U, V, W, +UG, −UG, BR1, BR2, and the pins of the FIF
interfaces still carry dangerous voltage for at least 3 minutes after
power−off.
– the power terminals L1, L2, L3; U, V, W, +UG, −UG, BR1, BR2, and the pins of
the FIF interfaces carry dangerous voltage when the motor is stopped.
– the relay outputs K11, K12, K14 can carry dangerous voltage when the
drive controller is disconnected from the mains.
(
Stop!
Short circuit and static discharge
The device contains components that can be damaged in case of a short circuit
or static discharge.
Possible consequences:
ƒ The device or parts of it are destroyed.
Protective measures:
ƒ Always switch off the voltage supply when working on the device. This must
be especially observed in the following cases:
– Before opening the housing.
– Before connecting/disconnecting connectors.
– Before plugging in / removing modules.
ƒ Before working on the device, the personnel must be free of electrostatic
charge.
ƒ Do not touch the contacts.
