Mechanical installation
Standard devices in the power range 15 ... 30 kW
Mounting with fixing brackets (standard)
4
l
121 EDK82EV903 DE/EN/FR 5.1
Controller variant "3xx" (with fully mounted footprint filter)
For this mounting variant you require controller type E82EVxxxK4B3xx.
2
3
1
m
g
³
150 mm
c
k
c1
b1
³
100 mm
d1
d2 d
a
l
e
b
a
3 Nm
26.5 lb-in
h
l
0
³ 50 mm ³ 50 mm
8200vec293
 Loosen both screws to be able to remove the housing cover. The assembly kit is located under
the housing cover.
‚ Installation of mounting angles
ƒ Dimensions
0
Arrange the controllers side by side with spacing to be able to disassemble the eyebolts.
Dimensions [mm]
8200 vector integr. mains
filter
2)
a b b1 c c1 d d1 d2 e 1) g k m
E82EV153K4B3xx E82ZN22334B230
250 456 350 206 22 402 24 370 340 6.5 24 11 E82EV223K4B3xx E82ZN22334B230
E82EV303K4B3xx E82ZN30334B230
1) If the function module is attached: observe mounting clearance and cable bending radius. The terminals of function
modules in PT design protrude above the housing by 8 mm.
2) The integrated mains filters are only designed for controller operation at rated power. Different filters with different
dimensions are possible (
^ 140
).
