Mechanical installation
Standard devices with a power of 55 kW
Mounting with fixing brackets (standard)
l
130
EDK82EV903 DE/EN/FR 5.1
Dimensions [mm]
8200 vector
a
b
b1
c
c1
d
d1
e
1)
g
k
m
E82EV553K4B2xx
340
672
591
28.5
283
615
38
285
11
28
18
1)
If the function module is attached: observe mounting clearance and cable bending radius. The terminals of function
modules in PT design protrude above the housing by 8 mm.
Controller variant "3xx" (with fully mounted footprint filter)
For this mounting variant you require controller type E82EVxxxK4B3xx.
a
c1
b
d
d1
l
c
³ 50 mm
³ 50 m
g
m
k
0
³ 100 mm
³ 100mm
e
8200vec298
Loosen both screws to be able to remove the housing cover. The assembly kit is located under
the housing cover.
Installation of mounting angles
Dimensions
0
Arrange the controllers side by side with spacing to be able to disassemble the eyebolts.
Dimensions [mm]
8200 vector
integr. mains
filter
2)
a
b
b1
c
c1
d
d1
d2
e
1)
g
k
m
E82EV553K4B3xx
E82ZN55334B230
340
729
591
283 28.5 672
38
615
375
11
28
18
1)
If the function module is attached: observe mounting clearance and cable bending radius. The terminals of function
modules in PT design protrude above the housing by 8 mm.
2)
The integrated mains filters are only designed for controller operation at rated power. Different filters with different
dimensions are possible (
