Data transfer
DRIVECOM profile parameters
7
Feldbus-Baugruppe 2113 INTERBUS
7.6
7.6.7
L
7.6-34 EDSIBS-1.0-06/2003
7.6.7.2 Monitoring parameters
If the transmission of the process data is inactive for longer than the set monitoring
time (PCD watchdog), the action set in the parameter ” process-data monitoring
selection code” (6004
hex
) will be activated.
Parameter name (Index) Subindex Data structure Data type Value range
Process data monitoring time
(6003
hex
)
0 S OS-1
OS: Octet
string,
length: 4
0 - 65535
(Lenze setting:
65535,
monitoring is switched off)
The parameter determines the reaction of the controller after the process data
monitoring time is over (6003
hex
).
Parameter name (Index) Subindex Data structure Data type Value range
Process data monitoring selection
code (6004
hex
)
0 S I16 0 (Lenze setting),
0 = No action
2:
Unit control command
„Inhibit voltage“ (controller
inhibit with latching in the
status ”SWITCH ON INHIBIT“)
3:
Unit control command
”Quick stop“ (quick stop
(QSP) with latching in the
status ”SWITCH ON
INHIBIT“).
Process data monitoring time
(6003
hex
)
Process data monitoring
selection code (6004
hex
)
