Data transfer
Process data channel configuration
7
Feldbus-Baugruppe 2113 INTERBUS
7.6
7.6.1
L
7.6-5 EDSIBS-1.0-06/2003
The parameter describes the process data which are sent from the controller to
the INTERBUS master (input data for the INTERBUS master). Paramters of the
described process data assignment of Lenze controllers can be assigned to the
sub-index values (see
( ¶ 7.6-7) ). Exception: The value for subindex 1 cannot be
changed.
Ensure that the parameters of the process data channel are only used once, i.e.
double assigment must be avoided (example: DC speed and speed setpoint are
sent via AIF-W1).
Parameter name (Index) Subindex Data structure Data type
PI data description (6000
hex
) 1 ... 41 R PBS(20
hex
)
) ) ) )
Note!
Only the valid subindex is displayed with the parameter 6000
hex
.
It is determined by PD!
Subindex Meaning Value Lenze setting
1 Number of process data [byte] PD S 2
2 Index PI data word 1 6041
hex
DRIVECOM status word
3 Subindex PI data word 1 00
4/5 No entry 00
6 Index PI data word 2 6044
hex
DRIVECOM speed
7 Subindex PI data word 2 00
8/9 No entry 00
10 Index PI data word 3 5CA5
hex
AIF-OUT.W2
11 Subindex PI data word 3 02
hex
12/13 No entry 00
14 Index PI data word 4 5CA5
hex
AIF-OUT.W3
15 Subindex PI data word 4 03
hex
16/17 No entry
18 Index PI data word 5 5CA5
hex
AIF-OUT.W4
19 Subindex PI data word 5 04
hex
20/21 No entry
22 Index PI data word 6 5CA5
hex
AIF-OUT.W5
23 Subindex PI data word 6 05
hex
24/25 No entry
26 Index PI data word 7 5CA5
hex
AIF-OUT.W6
27 Subindex PI data word 7 06
hex
28/29 No entry
30 Index PI data word 8 5CA5
hex
AIF-OUT.W7
31 Subindex PI data word 8 07
hex
32/33 No entry
34 Index PI data word 9 5CA5
hex
AIF-OUT.W8
35 Subindex PI data word 9 08
hex
36/37 No entry
38 Index PI data word 10 5CA5
hex
AIF-OUT.W9
39 Subindex PI data word 10 09
hex
40/41 No entry
PI data description (6000
hex
) 34
