Data transfer
Process data channel configuration
7
Feldbus-Baugruppe 2113 INTERBUS
7.6
7.6.1
L
7.6-6 EDSIBS-1.0-06/2003
The parameter describes the process data which are sent to the controller from
the INTERBUS master (output data for the INTERBUS master). Parameters of the
described process data of Lenze controllers can be assigned to subindex values
(see
( ¶ 7.6-7) ). Exception: The value for subindex 1 cannot be changed.
Ensure that the parameters of the process data channel are only used once, i.e.
double assigment must be avoided (example: DC speed and speed setpoint are
sent via AIF-W1).
Parameter name (Index) Subindex Data structure Data type
PO data description (6001
hex
) 1 ... 41 R PBS(20
hex
)
Subindex Meaning Value Lenze setting Index 6002/
Bit
1 Number of process data [byte] PD S 2
2 Index PO data word 1 6040
hex
DRIVECOM control word 0
3 Subindex PO data word 1 00
4/5 No entry 00 1
6 Index PO data word 2 6042
hex
DRIVECOM speed setpoint 2
7 Subindex PO data word 2 00
8/9 No entry 00 3
10 Index PO data word 3 5CA7
hex
AIF-IN.W2 4
11 Subindex PO data word 3 02
hex
12/13 No entry 00 5
14 Index PO data word 4 5CA7
hex
AIF-IN.W3 6
15 Subindex PO data word 4 03
hex
16/17 No entry 7
18 Index PO data word 5 5CA7
hex
AIF-IN.W4 8
19 Subindex PO data word 5 04
hex
20/21 No entry 9
22 Index PO data word 6 5CA7
hex
AIF-IN.W5 10
23 Subindex PO data word 6 05
hex
24/25 No entry 11
26 Index PO data word 7 5CA7
hex
AIF-IN.W6 12
27 Subindex PO data word 7 06
hex
28/29 No entry 13
30 Index PO data word 8 5CA7
hex
AIF-IN.W7 14
31 Subindex PO data word 8 07
hex
32/33 No entry 15
34 Index PO data word 9 5CA7
hex
AIF-IN.W8 16
35 Subindex PO data word 9 08
hex
36/37 No entry 17
38 Index PO data word 10 5CA7
hex
AIF-IN.W9 18
39 Subindex PO data word 10 09
hex
40/41 No entry 19
PO data description (6001
hex
) 35
