Data transfer
Device control
7
Feldbus-Baugruppe 2113 INTERBUS
7.6
7.6.5
L
7.6-28 EDSIBS-1.0-06/2003
7.6.5 Device control
) ) ) )
Note!
Deactivate the DRIVECOM control if you want to use the device
control (AIF-CTRL). For this use either code L-C1911 or the DIP
switch S7 (
^ 7.5-1 )
If you use the device control AIF-CTRL, the control information is determined by
the control inputs (terminal)
( ¶ 7.6-3) .
Explanation: Fig. 7.6-9
l Status word:
The controller status word AIF-STAT contains information about the current
controller status.
l Commands
– in the DRIVECOM parameter ” Control word“ are switched off and cannot
change the controller status.
– for changing the controller status are to be entered through the
corresponding control input.
npmGG
`íêäK Éå~ÄäÉGG `íêäK áåÜáÄáíGG
~мнзг~нбЕ~дду пЬЙе
нЬЙ бебнб~дбл~нбзе бл
ЕзгйдЙнЙЗ
qofm EÑ~ìäíF
qofm êÉëÉíGG
Switch on unit
pн~нмл пзкЗ сссс сссс ñMññ MMMM
NOT READY TO SWITCH ON
READY TO SWITCH ON
pн~нмл пзкЗ сссс сссс ñMNñ MMMN
SWITCHED ON
pн~нмл пзкЗ сссс сссс ñMNñ MMNN
OPERATION ENABLED
pн~нмл пзкЗ сссс сссс ñMNñ MNNN
~мнзг~нбЕ~дду
Fault
pн~нмл пзкЗ сссс сссс ñMññ NMMM
kçíÉW
qЬЙ нЙкгл г~квЙЗ пбнЬ GG ~кЙ Езгг~еЗл
Fig. 7.6-9 Status diagram for device control AIF-CTRL
