Commissioning
Possible settings with INTERBUS master
7
Feldbus-Baugruppe 2113 INTERBUS
7.5
7.5.3
L
7.5-4 EDSIBS-1.0-06/2003
7.5.3 Possible settings with INTERBUS master
) ) ) )
Note!
Conditions for setting through the INTERBUS master:
Switch S1 ... S7 = OFF
l The configurations set for the codes L-1910, L-1911 and
L-1912 get active with switching on.
l The settings can be changed.
l Switch off the voltage supply of the fieldbus module and
afterwards on again, in order to activate changed settings.
As a maximum the data word sum (PD + PCP) is to amount to 10
words.
Index detection: 24575 - Lenze code number (L-C xxxx )
Impermissible settings are indicated by the yellow bus LED
(communication)
( ¶ 7.4-1) .
Code Values Explanation
L-C1910 2 ... 20 (1 ... 10 words) Number of process data bytes
(2 Process data bytes = 1 Process data word)
L-C1911 0: Device control AIF-CTRL Operation with device control AIF-CTRL or
1: DRIVECOM control
p
operation with DRIVECOM-Profil 21
L-C1912 Number of parameter
data words (PCP)
ID code Number of parameter data words (PCP)
0 3
hex
1 E3
hex
2 E0
hex
4 E1
hex
Code Explanation
L-C1915 Display of the current switch positions S1 ... S4 for number of process data words
L-C1916 Display of the current position of switch S7 L-C1916 Display of the current position of switch S7.
L C1917 Displa of c rrent s itch positions S5/S6 for n mber of parameter data ords (PCP) L-C1917 Display of current switch positions S5/S6 for number of parameter data words (PCP) L-C1917 Display of current switch positions S5/S6 for number of parameter data words (PCP). L-C1917 Display of current switch positions S5/S6 for number of parameter data words (PCP).
Display codes
