Feldbus-Baugruppe 2113 INTERBUS
7.4
7.4.3
L
7.4-4 EDSIBS-1.0-06/2003
Pos. Element Explanation
1 INTERBUS master with
interface module The bus system is a master-slave system, i.e. an INTERBUS master is connected
to several field devices (slaves).
2 INTERBUS loop bus
terminal The bus terminal connects a long distance bus to a peripheral bus.
3 Remote bus
Fig. 5.4-2 Pos. 3 The following connections are possible with remote buses:
• Connections between INTERBUS master interface module and first bus
terminal or first 2113 fieldbus module.
• Connection between bus terminal and 2113 fieldbus module
• Connection between two 2113 fieldbus modules
3.1 Long distance bus module Bus participant in the long distance bus; e.g. Lenze controller with INTERBUS
module (slave). Networking does not require bus terminals.
3.2 Remote bus cable Connects the INTERBUS master interface module with the bus terminal and/or
the long distance bus modules.
4 INTERBUS loop,
peripheral bus
Fig. 5.4-2 Pos. 4 Connection in a peripheral-bus station
A peripheral-bus station consists of:
• a bus terminal (Fig. 5.4-2 pos. 2)
• up to eight peripheral bus modules (Fig. 5.4-2 pos. 3)
4.1 INTERBUS loop module Bus participant in the INTERBUS loop; e.g. Lenze controller with INTERBUS loop
module 2112
4.2 INTERBUS loop cable Connection within the loop
Features:
Communication medium
RS485
Network topology Ring
Maximum number of
controllers Dependent on INTERBUS master (e.g. Phoenix Contact G4-Master).
For the following data, always the smaller value applies dependent on the fact, whether
PCP communication is available or not:
• With PCP communication: 62 or
• Without PCP communication: 256/number PD
Baud rate / cable length Baud rate Maximum cable length between
neighbouring participants
500 kBit/s 400 m
2 MBit/s 150 m
Specification of INTERBUS remote bus cable 26
Cable type Yard goods:
IBS RBC Meter-T, order No. 28 06 28 6 (Fa. Phoenix Contact)
Number of conductors 3 x 2, paired with common shielding
Conductor cross-section > 0.2 mm 2
DC cable resistance < 96 Ω/km
Impedance, characteristic 120 Ω ± 20 % (f = 64 kHz)
100 Ω ± 15 Ω (f > 1 MHz)
Capacitance per unit length < 60 nF/km (f = 800 Hz)
If necessary, supply the 2113 fieldbus module with a separate supply voltage 24
V DC via the two-pole plug connector
±10 %.
Plug connector Name Explanation
+ Vcc24 External supply 24 V DC ± 10 %, 120 mA
- GND24 Reference potential for external voltage supply
Use a separate power supply unit in each control cabinet.
Controller External voltage supply
820X Always required
821X / 822X / 824X and
93XX Only necessary if the mains which supply the corresponding controllers is to be switched
off but the communication must not be interrupted.
8200 vector See information in “internal DC voltage supply”
External DC voltage supply 27
