Parameter values of process data preconfiguration
7
Feldbus-Baugruppe 2113 INTERBUS
7.8
7.8.2
L
7.8-5
EDSIBS-1.0-06/2003
7.8.2.2
PO-data
L-C0009 L-C1910
*)
L-C1911
*)
Index 6001, subindex:
2 / 3
6 / 7
10 / 11
14 / 15
18 / 19
22 / 23
26 / 27
30 / 31
34 / 35
38 / 39
11
4000
0
5F78 / 0
5CA7 / 1
12
4000
0
5CA7 / 1
5CA7 / 2
13
4000
0
5CA7 / 2
5CA7 / 3
14
4000
10000
6040 / 0
6042 / 0
15
4000
10000
6040 / 0
6052 / 0
16
4000
10000
6040 / 0
5CA7 / 1
17
4000
0
5F78 / 0
6042 / 0
18
4000
0
5F78 / 0
6052 / 0
21
6000
10000
6040 / 0
6042 / 0
5CA7 / 2
5CA7 / 3
5CA7 / 4
5CA7 / 5
5CA7 / 6
5CA7 / 7
5CA7 / 8
5CA7 / 9
22
6000
10000
6040 / 0
6052 / 0
5CA7 / 2
5CA7 / 3
5CA7 / 4
5CA7 / 5
5CA7 / 6
5CA7 / 7
5CA7 / 8
5CA7 / 9
23
6000
10000
6040 / 0
5CA7 / 1
5CA7 / 2
5CA7 / 3
5CA7 / 4
5CA7 / 5
5CA7 / 6
5CA7 / 7
5CA7 / 8
5CA7 / 9
24
6000
10000
6040 / 0
5CA7 / 2
5CA7 / 3
5CA7 / 4
5CA7 / 5
5CA7 / 6
5CA7 / 7
5CA7 / 8
5CA7 / 9
5CA7 / 10
25
6000
0
5F78 / 0
5CA7 / 1
5CA7 / 2
5CA7 / 3
5CA7 / 4
5CA7 / 5
5CA7 / 6
5CA7 / 7
5CA7 / 8
5CA7 / 9
26
6000
0
5F78 / 0
5CA7 / 2
5CA7 / 3
5CA7 / 4
5CA7 / 5
5CA7 / 6
5CA7 / 7
5CA7 / 8
5CA7 / 9
5CA7 / 10
27
6000
0
5CA7 / 1
5CA7 / 2
5CA7 / 3
5CA7 / 4
5CA7 / 5
5CA7 / 6
5CA7 / 7
5CA7 / 8
5CA7 / 9
5CA7 / 10
*)
= This entry is only effective if switches S1 ... S7 = OFF.
