Installation

Electrical installation

7

Feldbus-Baugruppe 2113 INTERBUS

7.4
7.4.3

L

7.4-6

EDSIBS-1.0-06/2003

7.4.3.1

Connection from the INTERBUS

2113

L

INTERBUS

Bus

Drive

OPE

N

1 2

3 4

5 6

7 8

PD

Length

PCPDriveco

m

Baud

24V

DC

_

+

OUT

IN

2113IBU010

IN

1

6

5

9

2113IBU012

Sub-D pin connector (IN)
Pin

Name

Input/output

Explanation

1

DO1

Input

RS485: DO1 not inverted

2

DI1

Output

RS485: DI1 not inverted

3

GND

Reference potential

4

free

5

Vcc5

5 V DC

6

/DO1

Input

RS485: DO1 inverted

7

/DI1

Output

RS485: DI1 inverted

8

Vcc5

5 V DC

9

free

Tab. 7.4-1

Pin assignment of the Sub-D pin connector (IN)
