Landoll 3130 SERIES WING PACKER User Manual
Page 25
3-13
Figure 3-11 Smooth Roller Gang Assembly- Main Frame (Small Models)
SMOOTH ROLLER GANG ASSEMBLY - MAIN FRAME (SMALL MODELS)
ITEM
PART NO.
DESCRIPTION
QTY.
1
43-1012
BEARING HANGER
3
EP6578
FLANGE
3
EP6577
FLANGE WITH ZERK
3
7745-37
BEARING WITH LOCK COLLAR
3
21999
CARRIAGE BOLT, 1/2” X 1-1/2”
12
15398
LOCK WASHER, 1/2”
12
15388
HEX NUT, 1/2”
12
2
41-0017
SMOOTH ROLLER, 17”
37
41-0019
SMOOTH ROLLER, 19”
37
3
1D70155
AXLE, MAIN FRAME
1
