Table 3-4 – Landoll 875 Series Tilloll User Manual
Page 31
ASSEMBLY INSTRUCTIONS
3-15
Table 3-4: Hydraulic Hose Installation - 18’, 21’, 25’-6” Fold Models
ITEM
PART NO.
HOSE LENGTH (MODEL USED)
A
116489
3/8 X 64 (875-18)
153843
3/8 X 67 (875-21)
116490
3/8 X 78” (875-25)
B
71508987
3/8 X 86 (875-18 & 875-21)
116433
3/8 X 90 (875-25)
C
123547
3/8 X 56 (875-18 & 875-21)
116489
3/8 X 64 (875-25)
D
1-397-010369036
3/8 X 36 (875-18)
71508992
3/8 X 50 (875-21)
123547
3/8 X 56 (875-25)
E
137602
3/8 X 27 (875-18 & 875-21)
71508984
3/8 X 42 (875-25)
F
71508992
3/8 X 50 (875-18)
153843
3/8 X 67 (875-21)
116490
3/8 X 78 (875-25)
G
153343
3/8 X 67 (875-18 & 875-21)
116490
3/8 X 78 (875-25)
H
116490
3/8 X 78 (875-18)
147583
3/8 X 72 (875-21 & 875-25)
J
137602
3/8 X 27 (875-18)
123547
3/8 X 56 (875-21)
116489
3/8 X 64 (875-25)
