Figure 3-4: frame assembly - fold models – Landoll 875 Series Tilloll User Manual
Page 21
ASSEMBLY INSTRUCTIONS
3-5
Figure 3-4: Frame Assembly - Fold Models
5/8-11 HEX
LOCK NUT
SHORT WING
SUPPORT
U-BOLT
HINGE PIVOT
BOLT
WING BRACKET
(25’-6”) (PLACE
AS SHOWN)
10” FOR
PLACEMENT
RIGHT WING
1/4 X 2
COTTER PIN
HINGE PIN
1” FLAT
WASHER
LEFT WING
1-8 HEX
LOCK NUT
WING BRACKET
(18’, 21’)
ROLLER WING
EXTENSION
545-106286-op
