MOUNTING DAY LIGHT SENSOR:
Day Light Sensor should be mounted on the dash or fairing. It should not
be facing the front of the motorcycle, in order to avoid false triggers at
night from on-coming vehicles.
FLUSH MOUNT
n
Chose an appropriate location for the
Daylight Sensor - it faces skyward and
should receive unobstructed sunlight.
o
Start with a small pilot hole. Finish with
a 10mm (25/64”) hole.
p
Feed the Sensor from behind the panel.
q
Insert the Split Bushing around the
cable, as shown.
r
Move the Bushing up toward the
serrated neck of the Sensor.
s
Push the assembly firmly in the hole,
until it locks-in - do not pull the cable.
FLEXIBLE MOUNT
Alternatively, you can zip-tie the Sensor to a brake cable or a bracket, as
long as it receives unobstructed sunlight. The sense head is encased in
elastomer to be waterproof.
The sensitivity is adjustable for distinct levels by programming. Depending
on the location you have chosen, or due to seasonal changes in weather
conditions you may want to choose a different level. The instructions are
described in more detail on the next page.
