STM-2 Operating Manual
Chapter 4
STM-2 LabVIEW Operation
4.1 Introduction
STM-2 LabVIEW Application is capable of displaying Rate, Thickness, and Crystal
Life for one STM-2 and the connected sensor. STM-2 LabVIEW Application has the
option to use Multi-layer mode to enable a cumulative Substrate Thickness and
independent Density, Z-Ratio, Tooling, and Sample parameters for each film to
allow for multi-layer monitoring capabilities. STM-2 LabVIEW Application can also
operate in Simulate mode without a connected STM-2.
4.2 Installing the STM-2 LabVIEW Application
4.2.1 Installing the Protocol Server
1 Insert the Thin Film Manuals CD into the CD drive on the computer that will
be connected to STM-2.
2 Click Windows Explorer or
File Explorer >> Computer >> (CD drive letter:) >> Common Software.
3 Double click setup_smdp_svr_lv.exe. The Zip Self-Extractor window will
display.
4 Click Unzip. The SMDP Serial Protocol Server window will display.
5 On the Destination Directory pane, click Browse to select the location where
all software will be installed.
6 Click Next.
7 Read the license agreement.
8 Click I accept License Agreement(s).
9 Click Next.
10 Review the summary of information.
11 Click Next. Installation Complete will display.
12 Click Next. The Setup Wizard pane will display.
13 Click Next. The Confirm Installation pane will display.
14 Click Next.
15 Read the license agreement.
16 Click I Agree.
17 Click Next. Installation Complete will display.
18 Click Close.
19 Click Close on the Zip Self-Extractor.
