STM-2 Operating Manual
3.3.1.4 Print
Click to print all of the current views of the STM-2 window (refer to
) or, print only the current window displayed.
NOTE: If the print setup window has been configured once during a session, the
parameters selected will not be able to be changed until the software is
exited and reloaded.
3.3.1.5 Screen Image to File
This list item will display a list of options regarding screen images.
Current View to JPG . . . . . . . . . . . Places a JPEG image of the current window
into the default Captures folder located in
Local Disk (C:) >> Program Files >>
INFICON >> STM-2 >> captures.
All Views to JPGs. . . . . . . . . . . . . . Places JPEG images of the current views of
the STM-2 window into the default Captures
folder located in Local Disk (C:) >>
Program Files >> INFICON >> STM-2 >>
captures.
Select JPG Folder . . . . . . . . . . . . . Displays a window to select the location and
name of the folder where the JPEG screen
images will be saved.
3.3.2 Edit Menu
Provides options to customize graph, display, and sample settings (see
).
Figure 3-6 Edit menu
3.3.2.1 Graph Settings
Click to display a window to configure the settings for Rate, Thickness, and
Frequency graphs. Also provides customization of line colors, axis formatting, and
scrolling.
NOTE: Graph Settings is disabled while monitoring.
