Beckett BRYAN STEAM CF2500A - Manual (Page 8)

Burnham Corporation PF-5 Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate
Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange
Insertion
504 CF800 BCF403 CF60KH 5.45 4.50x45P 2-1/2 5 10 N/A 140 51628 3.00"
505 CF1400 BCF205 CF66KD 6.80 3.50x45P 3 25 50 150 300 51629 3.375"
506 CF1400 BCF205 CF66KD 8.30 4.50x45P 4 30 60 150 300 51629 3.375"
507 CF1400 BCF205 CF66KD 9.80 5.50x45P 5 35 70 150 300 51629 3.375"
508 CF2300A BCF304 CF66KG 11.20 6.00x45P 2 20 70 150 300 51630 3.375"
509 CF2300A BCF304 CF66KG 12.60 7.00x45P 2-1/2 20 85 150 300 51630 3.375"
510 CF2300A BCF304 CF66KG 14.00 8.00x45P 3 25 95 150 300 51630 3.375"
511 CF2300A BCF304 CF66KG 15.50 8.50x45P 4 25 100 150 300 51630 3.375"
512 CF2300A BCF304 CF66KG 17.00 9.50x45P 4 30 105 150 300 51630 3.375"
513 CF2500A BCF1801 CF66KP 18.40 5.00x60P (2) 3 23 35 300 300 51630 3.375"
514 CF2500A BCF1801 CF66KP 19.50 5.50x60P (2) 4 25 40 300 300 51630 3.375"
515 CF2500 BCF1801 CF66KP 21.00 6.00x60P (2) 4-1/2 25 50 300 300 51630 3.375"
516 CF2500 BCF1801 CF66KP 22.50 6.50x60P (2) 5 25 50 300 300 51630 3.375"
517 CF3500A BCF1301 CF80KM 24.00 7.00x60PLP (2) 2 30 80 300 300 51630 4.25"
518 CF3500A BCF1301 CF80KM 25.50 7.50x60PLP (2) 3 32 95 280 280 51630 4.25"
519 CF3500A BCF1301 CF80KM 27.00 7.50x60PLP (2) 3-1/2 35 105 300 300 51630 4.25"
520 CF3500A BCF1301 CF114KR 28.50 8.00x60P (2) 4 37 95 300 300 51631 5.00"
521 CF3500A BCF1301 CF114KR 29.90 8.50x60P (2) 4 40 103 300 300 51631 5.00"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
Page 7
