Beckett BRYAN STEAM CF2500A - Manual (Page 30)

Vaillant Corporation F200 Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate
Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange
Insertion
F200-5 CF500 BCF809 CF80KK 2.25 2.00x45AS 1/2 3-1/2 0 N/A 140 51311 5.00"
F200-6 CF500 BCF809 CF80KK 2.75 2.50x45AS 1-1/2 3-1/2 0 N/A 140 51311 5.00"
F200-7 CF800 BCF403 CF80KHS 3.25 2.75x45AS 3 2 0 N/A 140 51311 5.00"
F200-8 CF800 BCF403 CF80KHS 4.00 3.50x45S 2-1/2 5-1/2 0 N/A 140 51311 5.00"
F200-9 CF800 BCF403 CF80KHS 4.75 4.00x45S 3-1/2 7 0 N/A 140 51311 5.00"
F200-10 CF1400 BCF205 CF66KD 5.50 3.00x45S 1 20 35 150 300 51312 5.00"
F200-11 CF1400 BCF205 CF66KD 6.30 3.50x45S 1 28 55 150 300 51312 5.00"
F200-12 CF1400 BCF205 CF66KD 7.00 4.00x45S 2 28 80 150 300 51312 5.00"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
Page 29
