Peerless Boiler SC Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate
Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange
Insertion
SC05 CF500 BCF809 CF60KK 3.00 2.50x60B 2 7 1 N/A 140 51311 2.50"
SC06 CF500 BCF809 CF60KK 3.50 3.00x60B 3 10 10 N/A 140 51311 2.50"
SC07 CF800 BCF403 CF60KH 4.00 3.25x45P 1 6 0 N/A 150 51311 2.50"
SC08 CF800 BCF403 CF60KH 4.50 3.75x45P 2 7 1 N/A 140 51311 2.50"
SC09 CF800 BCF403 CF60KH 5.00 4.00x30P 3 7 2 N/A 150 51311 2.50"
SC10 CF800 BCF403 CF60KH 5.50 4.50x30P 4 10 4 N/A 150 51311 2.50"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
Peerless Boiler TC Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate
Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange
Insertion
TC-04 CF1400 BCF205 CF66KE 8.00 5.00x45P 2 40 70 150 300 51629 4.875"
TC-05 CF1400 BCF205 CF66KE 10.40 6.00x45P 4 40 90 150 300 51629 4.875"
TC-06 CF2300A BCF304 CF66KG 12.60 7.50x45P 1-1/2 20 40 150 300 51630 4.875"
TC-07 CF2300A BCF304 CF66KG 15.00 9.00x45P 3-1/2 30 55 150 300 51630 4.875"
TC-08 CF2300 BCF304 CF66KG 17.40 10.00x45P 5 30 60 150 300 51630 4.875"
TC-09 CF2300A BCF304 CF66KS 19.60 11.00x45P 3 30 70 150 300 51630 4.875"
TC-10 CF2500 BCF1801 CF66KP 22.00 6.50x45P (2) 6 18 40 300 300 51630 4.875"
TC-11 CF2500 BCF1801 CF66KP 24.50 7.00x45P (2) 8 28 90 300 300 51630 4.875"
TC-12 CF3500A BCF1301 CF80KM 26.50 8.00x45P (2) 7 32 90 300 300 51630 4.875"
TC-13 CF3500A BCF1301 CF114KR 29.00 9.00x60P (2) 7 50 100 300 300 51631 5.375"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
Page 23
