Slant/Fin Liberty Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate
Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange
Insertion
LD-60 CF375 BCF3907 CF56KZ 2.60 2.25x45P 1 10 3 N/A 135 51311 2.00"
LD-60 CF375 BCF3907 CF56KZ 2.85 2.25x45P 2 10 2 N/A 160 51311 2.00"
LD-70 CF375 BCF3907 CF56KZ 3.00 2.50x45SS 3 10 4 N/A 145 51311 2.00"
LD-70 CF375 BCF3907 CF56KZ 3.10 2.50x45SS 4 10 4 N/A 155 51311 2.00"
LD-70 CF375 BCF3907 CF56KZ 3.35 2.75x60B 5 10 4 N/A 148 51311 2.00"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
