Easco Boiler SM5 Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate
Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange
Insertion
20 CF800 BCF403 CF100KH 5.80 4.50x45P 3 10 3 150 N/A 51628 5.00"
25 CF1000 BCF101 CF102KD 7.30 4.00x45P 4 20 N/A 300 N/A 51629 5.00"
30 CF1400 BCF205 CF102KE 8.70 5.00x45P 7 20 40 150 300 51629 5.00"
35 CF1400 BCF205 CF102KE 10.20 5.50x45P 9 30 70 150 300 51629 5.00"
40 CF2300A BCF304 CF102KG 11.70 7.00x45P 0 16 30 150 275 51630 5.00"
50 CF2300A BCF304 CF102KG 14.60 8.50x45P 3 20 40 150 275 51630 5.00"
60 CF2300A BCF304 CF102KG 17.50 10.00x45P 6 20 70 150 300 51630 5.00"
60S CF2300A BCF304 CF102KG 17.50 10.00x45P 6 20 70 150 300 51630 5.00"
70 CF2500 BCF1801 CF102KP 20.40 6.00x45P (2) 8 40 90 275 275 51630 5.00"
80 CF3500 BCF1301 CF80KM 23.30 6.50x45P (2) 7 30 80 300 300 51630 5.00"
90 CF3500 BCF1301 CF114KR 26.20 7.50x45P (2) 7-1/2 40 90 300 300 51631 5.00"
100 CF3500 BCF1301 CF114KR 29.20 8.50x45P (2) 8 50 100 280 280 51631 5.00"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only. Flange requires an additional adapter plate.
