Crown Boiler VH Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate
Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange
Insertion
VH8 CF2300A BCF304 CF66KG 10.20 6.00x45P 0 16 30 125 300 51630 5.75"
VH9 CF2300A BCF304 CF66KG 12.00 7.00x45P 0 20 40 125 300 51630 5.75"
VH10 CF2300A BCF304 CF66KG 14.00 8.00x45P 1-1/2 20 50 125 300 51630 5.75"
VH11 CF2300A BCF304 CF66KG 15.80 9.00x45P 2-1/2 30 60 125 300 51630 5.75"
VH12 CF2300A BCF304 CF66KG 17.60 10.00x45P 3 40 70 125 300 51630 5.75"
VH13 CF2500A BCF3001 CF66KP 19.60 5.00x45P (2) 1 20 40 300 300 51630 5.75"
VH14 CF2500 BCF1801 CF66KP 21.50 6.00x45P (2) 2 20 40 300 300 51630 5.75"
VH15 CF2500 BCF1801 CF66KP 23.50 6.50x45P (2) 4 20 40 300 300 51630 5.75"
VH16 CF3500A BCF1301 CF80KM 25.00 7.50x45P (2) 7 30 70 300 300 51630 5.75"
VH17 CF3500A BCF1301 CF80KM 27.00 8.00x45P (2) 7 30 60 300 300 51630 5.75"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
