Peerless Boiler LC Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate
Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange
Insertion
LC04 CF800 BCF403 CF60KH 4.75 4.00x45P 2 0 9 N/A 140 51311 2.50"
LC05R CF800 BCF403 CF60KH 5.60 4.50x45P 2 0 10 N/A 140 51311 2.50"
LC05 CF1400 BCF205 CF66KD 6.10 3.50x45P 1/2 25 50 150 300 51629 3.50"
LC06 CF1400 BCF205 CF66KD 7.50 4.50x45P 1 25 60 150 280 51629 3.50"
LC07 CF1400 BCF205 CF66KD 8.80 5.00x45P 5 35 80 150 300 51629 3.50"
LC08 CF2300A BCF304 CF66KG 10.20 6.00x45P 0 20 35 150 280 51630 3.00"
LC09 CF2300A BCF304 CF66KG 11.60 6.50x45P 1 20 40 150 300 51630 3.00"
LC10 CF2300A BCF304 CF66KG 12.80 7.00x45P 2 25 50 150 300 51630 3.00"
LC11 CF2300A BCF304 CF66KG 14.20 8.50x45P 2-1/2 30 70 150 280 51630 3.00"
LC12 CF2300 BCF304 CF66KG 15.60 9.00x45P 3-1/2 35 90 150 300 51630 3.00"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
Peerless Boiler LCE Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate
Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange
Insertion
LCE-13 CF2300A BCF304 CF66KG 17.00 10.00x45P 6 30 80 150 290 51630 3.00"
LCE-14 CF2300A BCF304 CF66KS 18.40 11.00x45P 3 30 60 150 280 51630 3.875"
LCE-15 CF2300 BCF304 CF66KS 19.80 12.00x45P 3 30 100 150 275 51630 3.875"
LCE-16 CF2500 BCF1801 CF66KP 21.00 6.00x45P (2) 4 20 60 300 300 51630 3.00"
LCE-17 CF2500 BCF1801 CF66KP 22.50 6.50x45P (2) 6 35 60 300 300 51630 3.00"
LCE-18 CF3500A BCF1301 CF66KM 24.00 7.00x45P (2) 3-1/2 23 40 295 295 51630 4.250"
LCE-19 CF3500A BCF1301 CF66KM 25.00 7.50x45P (2) 5 25 40 275 275 51630 4.250"
LCE-20 CF3500 BCF1301 CF66KM 26.50 8.00x45P (2) 6 27 60 275 275 51630 4.250"
LCE-21 CF3500A BCF1301 CF114KR 28.00 8.00x45P (2) 5-1/2 30 80 300 300 51631 5.125"
LCE-22 CF3500A BCF1301 CF114KR 29.50 8.50x45P (2) 5-1/2 35 85 300 300 51631 5.125"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
Page 22
