Beckett BRYAN STEAM CF2500A - Manual (Page 19)

Hurst Cyclone Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate
Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange
Insertion
6HP CF500 BCF809 CF100KK 2.00 1.75x60B (D) 0 2 0 N/A 140 51311 N/A
10HP CF500 BCF809 CF100KK 3.50 3.00x60B 3 10 2 N/A 140 51311 N/A
15HP CF800 BCF403 CF140KH 4.50 4.00x60B 4-1/2 10 3 N/A 140 51312 N/A
20HP CF1400 BCF205 CF136KD 6.00 3.50x45P 1/2 20 40 150 300 51312 N/A
25HP CF1400 BCF205 CF136KD 7.50 4.50x45P 3 35 60 150 300 51312 N/A
30HP CF2300A BCF304 CF136KG 9.00 5.00x45P 1-1/2 30 40 150 300 51313 N/A
40HP CF2300A BCF304 CF136KG 12.00 7.00x45P 2 30 60 150 300 51313 N/A
50HP CF2300A BCF304 CF136KG 15.00 8.50x45P 3 35 75 150 300 51313 N/A
60HP CF2500 BCF1801 CF176KP 18.00 5.00x60P (2) 3 19 40 300 300 51313 N/A
70HP CF2500 BCF1801 CF176KP 21.00 6.00x60P (2) 4 26 50 300 300 51313 N/A
80HP CF3500A BCF1301 CF150KM 24.00 7.00x60P (2) 3 32 90 300 300 51630 N/A
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
Page 18
