Beckett BRYAN STEAM CF2500A - Manual (Page 11)

Columbia Boiler CT Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate
Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange
Insertion
CT-20 CF800 BCF403 CF100KJ 6.00 5.00x60P 3 7 0 N/A 150 51628 4.75"
CT-25 CF1000 BCF101 CF66KD 7.50 4.50x60P 3 5 N/A N/A 275 51629 4.75"
CT-25 CF1400 BCF205 CF66KD 9.00 5.50x60P 3 30 50 150 300 51629 4.75"
CT-35 CF2300A BCF304 CF66KG 10.50 6.00x45P 3 30 50 150 300 51630 4.75"
CT-50 CF2300A BCF304 CF66KG 15.00 9.00x60P 3 30 50 150 300 51630 4.75"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
Columbia Boiler CWH Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate
Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange
Insertion
CWH-780 CF800 BCF403 CF100KJ 6.00 5.00x60P 3 7 0 N/A 150 51628 4.75"
CWH-1200 CF1000 BCF101 CF66KD 9.00 5.50x60P 3 5 N/A N/A 275 51629 4.75"
CWH-1200 CF1400 BCF205 CF66KD 9.00 5.50x60P 3 30 50 150 300 51629 4.75"
CWH-1510 CF2300A BCF304 CF66KG 12.00 7.00x45SS 3 30 50 150 300 51630 4.75"
CWH-1810 CF2300A BCF304 CF66KG 14.00 8.00x60P 3 30 50 150 300 51630 4.75"
CWH-2460 CF2300A BCF304 CF66KG 18.00 10.00x60P 3 30 50 150 300 51630 4.75"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
Page 10
