Burnham Corporation MPC Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate
Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange
Insertion
MPC-4 CF500 BCF809 CF66KK 3.55 02.75x70B D 3 10 2 N/A 150 0 4.25"
MPC-5 CF800 BCF403 CF60KH 5.50 04.50x70B D 3 8.5 0 N/A 150 0 4.25"
MPC- 6 CF1400 BCF205 CF66KD 7.10 04.25x60B D 4 43 48 150 250 0 4.25"
MPC-7 CF1400 BCB8302 CF66KE 7.80 05.00x45B D 6 45 51 150 300 0 4.25'
MPC-8 CF2300A BCF304 CF66KG 10.20 06.00x45B D 1 37 47 150 300 0 4.25"
MPC-9 CF2500A BCF304 CF66KG 11.20 07.00x45B D 7 39 47 150 300 0 4.25"
MPC-10 CF2300A BCF304 CG66KG 13.40 08.00x45B D 9 43 54 150 280 0 4.25"
MPC-11 CF2500A BCF3001 CF66KP 15.00 04.50x45P H 0 22 35 275 275 0 4.25"
MPC-12 CF2500A BCF3001 CF66KP 16.60 05.00x45P H 2 23 41 300 300 0 4.25"
MPC-13 CF2500A BCF3001 CF66KP 18.20 05.50x45P H 5 24 38 300 300 0 4.25"
MPC-14 CF2500A BCF3001 CF66KP 19.20 06.00x45P D 6 26 43 275 275 0 4.25"
MPC-15 CF2500 BCF1801 CF66KP 21.50 06.50x45P H 9 25 40 275 275 0 4.25"
MPC-16 CF3500A BCF1301 CF144KR 23.00 07.00x45P H 7 29 42 275 275 0 5.125"
MPC-17 CF3500A BCF1301 CF114KR 24.50 07.50x45P H 8 30 51 275 300 0 5.125"
MPC-18 CF3500A BCF1301 CF114KR 26.00 07.00x45P H 7 29 42 275 275 0 5.125"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
