Peerless Boiler 7FDA Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate
Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange
Insertion
704 CF800 BCF403 CF60KH 3.95 3.50x70B 0 40 10 N/A 140 51311 2.50"
705 CF800 BCF403 CF60KJ 5.10 4.50x60B 1-1/2 40 10 N/A 140 51311 2.50"
706 CF800 BCF403 CF60KJ 6.20 5.00x60B 3 60 10 N/A 140 51311 2.50"
707 CF1400 BCF205 CF66KD 7.40 4.50x45B 3 35 60 150 300 51629 3.50"
708 CF1400 BCF205 CF66KD 8.50 5.00x45B 4-1/2 50 75 150 300 51629 3.50"
709 CF1400 BCF205 CF66KD 9.60 5.50x45B 5 50 80 150 300 51629 3.50"
710 CF2300A BCF304 CF66KG 10.80 6.00x45P 0 15 30 150 300 51630 3.00"
711 CF2300A BCF304 CF66KG 12.00 7.00x45P 0 20 40 150 300 51630 3.00"
712 CF2300A BCF304 CF66KG 13.00 7.50x45P 1 25 45 150 300 51630 3.00"
713 CF2300A BCF304 CF66KG 14.20 8.00x45P 2 30 50 150 300 51630 3.00"
714 CF2300A BCF304 CF66KG 15.40 9.00x45P 2-1/2 30 60 150 300 51630 3.00"
715 CF2300A BCF304 CF66KG 16.40 9.50x45P 4 40 65 150 300 51630 3.00"
716 CF2300 BCF304 CF66KG 17.60 10.00x45P 6 35 85 150 300 51630 3.00"
717 CF2500A BCF3001 CF66KP 18.80 5.50x45P (2) 1 18 40 300 300 51630 3.00"
718 CF2500A BCF3001 CF66KP 19.80 6.00x45P (2) 2-1/2 22 60 275 275 51630 3.00"
719 CF2500 BCF1801 CF66KP 21.00 6.00x45P (2) 4 21 60 300 300 51630 3.00"
720 CF2500 BCF1801 CF66KP 22.00 6.50x45P (2) 6 30 60 285 285 51630 3.00"
721 CF2500 BCF1801 CF66KP 23.50 7.00x45P (2) 8 35 70 280 280 51630 3.00"
722 CF3500A BCF1301 CF80KM 24.50 7.00x45P (2) 4 20 40 300 300 51630 4.25"
723 CF3500A BCF1301 CF80KM 25.50 7.50x45P (2) 5 22 50 290 290 51630 4.25"
724 CF3500 BCF1301 CF80KM 26.50 8.00x45P (2) 6 25 60 275 275 51630 4.25"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
