Page 29: Starfire ii, Series boiler
Smith Cast Iron Boilers
HE28
Series Boiler
Boiler
Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate
Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange
Insertion
HE28-4
CF1400
BCF205
CF66KF
7.80
4.50x45P
2
35
45
150
300
51629
3.875"
HE28-5
CF2300A
BCF304
CF66KG
9.50
5.50x60P
0
18
28
150
280
51630
3.875"
HE28-6
CF2300A
BCF304
CF66KG
11.20
6.50x60P
3
25
35
150
300
51630
3.875"
HE28-7
CF2300A
BCF304
CF66KG
13.90
8.00x60P
6
30
40
150
280
51629
3.875"
HE28-8
CF2500
BCF1801
CF66KP
16.40
5.00x45P
1
15
25
270
270
51630
3.875"
HE28-9
CF2500
BCF1801
CF66KP
18.20
5.50x45P
5
20
35
280
280
51630
3.875"
HE28-10
CF2500
BCF1801
CF66KP
20.80
6.00x60P
7
21
45
300
300
51630
3.875"
HE28-11
CF3500A
BCF1301
CF92KM
22.50
6.50x60P
4
24
50
300
300
51630
4.50"
HE28-12
CF3500A
BCF1301
CF114KR
25.10
7.50x60P
5
27
70
290
290
51631
5.50"
HE28-13
CF3500A
BCF1301
CF114KR
27.50
8.00x60P
6
30
70
290
290
51631
5.50"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
Utica Boiler
Starfire II
Series Boiler
Boiler
Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate
Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange
Insertion
SFM66
CF500
BCF809
CF60KK
2.25
2.00x60B
1
3
0
N/A
140
51311
1.50"
SFM77
CF500
BCF809
CF60KK
2.75
2.50x60B 2-1/2
5-1/2
0
N/A
140
51311
1.50"
6225
CF375
BCF3907
CF100KZ
2.25
2.00x45B
0
6
3
N/A
140
51311
2.250"
7275
CF375
BCF3907
CF100KZ
2.75
2.25x45B
1
4
5
N/A
140
51311
2.25"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
Page 28
