Burnham Corporation FDO Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate
Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange
Insertion
FDO-7 CF500 BCF809 CF60KK 2.25 2.00x45P 1 3-1/2 0 N/A 140 51311 4.375"
FDO-9 CF500 BCF809 CF60KK 2.75 2.25x45P 2 4 0 N/A 140 51311 4.375"
FDO-10 CF500 BCF809 CF60KK 3.00 2.75x45P 2 4 0 N/A 140 51311 4.375"
FDO-12 CF800 BCF403 CF60KH 4.00 3.50x45P 2 6 0 N/A 140 51311 4.375"
FDO-14 CF800 BCF403 CF60KH 4.50 4.00x45P 2 7 0 N/A 140 51311 4.375"
FDO-15 CF800 BCF403 CF60KH 5.00 4.50x45P 2 8 0 N/A 140 51311 4.375"
FDO-19 CF800 BCF403 CF60KJ 6.00 5.00x45P 3 10 3 N/A 140 51628 4.375"
FDO-24 CF1400 BCF205 CF66KD 7.50 4.50x45P 3 30 55 150 300 51629 4.375"
FDO-30 CF1400 BCF205 CF66KE 9.00 5.50x45P 1-1/2 45 75 150 300 51629 4.375"
FDO-38 CF2300A BCF304 CF66KG 12.00 7.00x45P 1 25 45 150 300 51313 4.375"
FDO-45 CF2300A BCF304 CF66KG 13.80 8.00x45P 1-1/2 25 60 150 300 51313 4.375"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
