Burnham Corporation V9 Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate
Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange
Insertion
V-903 CF500 BCF809 CF80KK 2.75 2.25x60P 2 10 5-1/2 N/A 140 51628 4.00"
V-904 CF500 BCF809 CF80KK 3.50 3.00x45P 3-1/2 10 5-1/2 N/A 140 51628 4.00"
V-905 CF800 BCF403 CF80KH 4.60 4.00x60P 4 10 5 N/A 140 51628 4.00"
V-906 CF800 BCF403 CF80KJ 5.80 5.00x60P 3 10 6 N/A 140 51628 4.00"
V-907 CF1400 BCF205 CF66KD 6.90 4.00x45P 3 35 60 125 300 51629 4.00"
V-908 CF1400 BCF205 CF66KE 8.00 4.50x45P 3 25 50 125 300 51629 4.00"
V-909 CF1400 BCF205 CF66KE 9.10 5.00x45P 3 30 55 125 300 51629 4.00"
V-910 CF1400 BCF205 CF66KE 10.20 5.50x45P 5-3/4 40 75 125 300 51629 4.00"
V-911 CF2300A BCF304 CF66KG 11.40 6.50x45P 1-1/2 38 45 125 300 51630 4.00"
V-912 CF2300A BCF304 CF66KG 12.60 7.00x45P 4 40 50 125 300 51630 4.00"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
Burnham Corporation V9A Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate
Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange
Insertion
V-903A CF500 BCF809 CF60KK 3.10 2.50x45P 2 10 3 N/A 150 51628 4.12"
V-904A CF800 BCF403 CF80KH 4.20 3.50x45P 1 8 0 N/A 150 51628 4.12"
V-905A CF800 BCF403 CF80KH 5.60 4.50x45P 2 10 6 N/A 150 51628 4.12"
V-906A CF1400 BCF205 CF66KD 7.00 4.00x60P 3 28 40 150 300 51629 4.12"
V-907A CF1400 BCF205 CF66KD 8.30 5.00x45P 4 30 65 150 275 51629 4.12"
V-908A CF1400 BCF205 CF66KEE 9.60 5.50x45P 1 35 85 150 300 51629 4.12"
V-909A CF2300A BCF304 CF66KG 11.60 7.00x45P 0 20 40 150 275 51630 4.12"
V-910A CF2300A BCF304 CF66KG 13.20 8.00x45P 1 20 60 150 275 51630 4.12"
V-911A CF2500A BCF1801 CF66KP 14.80 4.50x45P (2) 0 17 30 275 275 51630 4.12"
V-912A CF2500A BCF1801 CF66KP 16.40 5.00x45P (2) 0 20 40 275 275 51630 4.12"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
Page 9
