95-8444 16 10.1
Table 7—Infiniti Outputs
Table 6—Infiniti Sensor Compatibility
Infiniti Model Accepts
Combustible
• U9500A
Accepts inputs from Det-Tronics Catalytic Combustible gas sensor only.
Toxic and Oxygen Models
• U9500B Hydrogen Sulfide
• U9500C Oxygen
• U9500D Chlorine
• U9500E Carbon Monoxide
• U9500F Sulfur Dioxide
Accepts 4 to 20 mA inputs only.
• C7064E Hydrogen Sulfide Sensor
• C7065E Oxygen Sensor
• C7067E Chlorine Sensor *
• C7066E Carbon Monoxide Sensor
• C7068E Sulfur Dioxide Sensor
Hydrocarbon (HC)
• U9500H
Accepts inputs from the Det-Tronics PointWatch infrared hydrocarbon gas detector.
* External intrinsically-safe barrier required for hazardous area approval (I.S. barrier not
available from Det-Tronics).
Output Description
4 to 20 Milliamperes (Standard)
• The linear 4 to 20 mA output:
– corresponds to the field-programmed gas range.
– can be calibrated in the field for maximum accuracy.
– is user selectable for isolated or non-isolated use.
Refer to the “Setup ” section for programming information.
4 to 20 mA with Relays (Optional)
• Option includes a set of four relays:
–High Alarm
–Low Alarm
–Auxiliary Alarm
–Fault
• The High, Low and Auxiliary Alarm relays are programmable
as a group for either normally energized or normally de-energized
operation.
• Low Alarm, Auxiliary Alarm, and High Alarm relays are programmable as
a group for either latching or non-latching operation.
• Fault relay is normally energized with no faults. Faults are generally
non-latching, but faults that occur during calibration and warmup must be
reset.
• Latching relays are reset using either the Cal magnet or an external reset
switch (field installed, user supplied).
