f-10 95-8676 2.1
alarm latch Configuration
NoTe
Refer to “Alarm Relays” in the Specifications section of this manual for important information regarding alarm relays.
event log ID Codes
Calibration log ID Codes
aSCII proToCol
The RS485 serial port can be configured for ASCII protocol, which is intended for applications that don’t require custom
software on the host side. Off the shelf terminal emulation software can be used to receive messages from the device.
Percent by volume and sensor readings are sent once per second and user prompt messages are sent during the
calibration process to guide the user at each step. Default serial settings are 9600 baud, 1 stop bit, and no parity.
Protocol and serial parameters should be selected with the HART handheld communicator.
Description Code
Non-Latching 0
Latching 1
Description Code
Empty 0
Blocked Beam 1
Warm-up 2
Zero Drift 3
Low Alarm 4
High Alarm 5
Description Code
Empty 0
Zero Cal 1
Zero and Span 2
Failed Cal 3
