Det-Tronics PIRECL Infrared Carbon Dioxide Gas Detector PointWatch Eclipse User Manual

Page 40

E-8

95-8676

2.1

DeVICe SeTUp SUbMenU
1 basic Setup

1 Gas CO2 2.0%

2 PV Snsr unit Vol %

3 PV URV 2.00 Vol %

4 Device information

1 Manufacturer

2 Dev id (A number is used to identify a unique field device)

3 Tag

4 Long tag

5 Date

Descriptor (Text associated with the field device that can be used by the operator in any way)

Message (Text associated with the field device that can be used by the operator in any way)

Model

Write protect

2 Detailed Setup

1 Gas Type

2 Sensor Information

1 PV USL (Upper sensor limit value defines the maximum usable value for the upper range of the sensor)

2 Active (Output value of the active sensor)

3 Reference (Output value of the reference sensor)

4 Ratio (Ratio of the active sensor over the reference sensor)

5 Absorption % (Gas absorption expressed in percent)

6 Span Factor (Number used in calibrating this specific device)

7 Snsr temp degC (Temperature of the sensor that is making the process measurement)

8 Vol % @ 100% FS (% volume of gas equal to 100% FS)

3 Write Protect

1 Password (A password is required to enable writing to the device)

2 Set Write Protect

–

Disable

–

Enable

–

Change Password

3 Write Protect

1 Basic Setup

2 Detailed Setup

3 Output Condition

4 Review
