E-9 95-8676 2.1
3 output Condition
Select and configure the output signal options for the Eclipse detector
1 Config Gas Alarms
1 High Alarm Level
2 High Alarm Latch
3 Low Alarm Level
4 Low Alarm Latch
NoTe
Refer to “Alarm Relays” in the Specifications section of this manual for important information regarding alarm relays.
2 Config fault out
1 Analog fault codes (This programs the analog output used to indicate faults)
– Eclipse
– PIR 9400
– User defined
3 Hart output
1 Poll addr (Address used by the host to identify a field device)
2 Num req preams (Number of Request Preambles)
4 Com Port
1 Protocol (Protocol for RS-485 communications)
– Modbus
– ASCII
2 Poll addr (Polling address for RS-485 communications)
3 Baud Rate (Baud rate for RS-485 communications)
– 1200
– 2400
– 4800
– 9600
– 19.2k
4 Parity (Parity for RS-485 communications)
– None
– Even
– Odd
4 review
Press to access the Review menu. This menu lists all of the parameters stored in the connected device, including
information about the measuring element, signal condition, and output. It also includes stored information about the
connected device such as tag, materials of construction, and device software revision.
factory Default
range 0-20000 ppm 0-2%/vol
Low Alarm Range
(% of range)
5-90% 5-50%
Default 75% 40%
High Alarm Range
(% of range)
10-90% 10-60%
Default 90% 60%
