Det-Tronics PIRECL Infrared Carbon Dioxide Gas Detector PointWatch Eclipse - Manual (Page 46)

f-5 95-8676 2.1
General Status bits
These bits are used to signal the current operating mode of the device.
eclipse Status Information (continued)
Description address Value
Min Temperature
40239 Float LSW
40240 Float MSW
Min Temp Hour
40241 Unsigned Long LSW
40242 Unsigned Long MSW
Min Temp (Since Reset)
40243 Float LSW
40244 Float MSW
Min Temp Hour (Since Reset)
40245 Unsigned Long LSW
40246 Unsigned Long MSW
Fixed 4 to 20 mA Value
40247 Float LSW
40248 Float MSW
Reserved 40249
Reserved 40250
Reserved 40251
Reserved 40252
Zero Ratio
40253 Float LSW
40254 Float MSW
Span Factor
40255 Float LSW
40256 Float MSW
5 Volt Power Supply Value
(As read by ADC)
40257 Float LSW
40258 Float MSW
12 Volt Power Supply Value
(As read by ADC)
40259 Float LSW
40260 Float MSW
24 Volt Power Supply Value
(As read by ADC)
40261 Float LSW
40262 Float MSW
name bit Description
Device Fault (any fault) 0 Set for all fault conditions
Calibration Active 1 Set during calibration
Warm up Mode 2 Set during warm-up
Low Alarm Active 3 Set while alarm is active
High Alarm Active 4 Set while alarm is active
Output Current Fixed 5 Set when output current is fixed
Modbus Write Protect 6 0 = Locked 1 = Unlocked
Calibration Input Active 7 True while the cal line is active
Magnetic Switch Active 8 True while the onboard magnetic switch is active
Hart Initiated Self Test 9 True when self test is initiated from the Hart interface
Reserved 10
Response Test Active 11 True during the gas response test.
Manual Self Test Active 12 True during manual self test
