C-1 95-8676 2.1
AppenDix c
IeCex approVal
The following items, functions and options describe the IECEx approval.
approVal
PointWatch Eclipse
® Infrared Carbon Dioxide Gas Detector, Model PIRECL Series.
IECEx ULD 04.0002X
Ex de IIC T4-T5 Gb
– OR –
Ex de [ib] IIC T4-T5 Gb
(with HART communication port)
T5 (Tamb –50°C to +40°C)
T4 (Tamb –50°C to +75°C)
IP66/IP67.
– OR –
IECEx ULD 04.0002X
Ex d IIC T4-T5 Gb
– OR –
Ex d [ib] IIC T4-T5 Gb
(with HART communication port)
T5 (Tamb –55°C to +40°C)
T4 (Tamb –55°C to +75°C)
IP66/IP67.
HART Communication Port:
Uo = 4.0V Co = 20μF
Io = 100mA Lo = 500μH
IeC Conditions of Certification (general):
• The Infrared Gas Detector model PIRECL shall be installed in places where there is a low risk of mechanical damage.
• The field wiring terminal connections are certified for a single wire in size from 0.2 to 2.5 mm
2 , (or two conductors with
same cross section 0.2 to 0.75 mm 2 ).The screws must be tightened down with a torque 0.4 to 0.5 Nm.
• The metal housing of the model PIRECL Infrared Carbon Dioxide Gas Detector must be electrically connected to earth
ground.
• The Infrared Gas Detector model PIRECL has an ambient temperature rating of –55°C to +75 °C.
• Alarm output latching requirement: High alarm outputs must be configured as latching, either as part of the alarm
operation of the gas detector itself (in stand-alone applications), or as a function of the “high alarm” indication within the
controller that is directly connected to the gas detector (for remote applications).
Special conditions for safe use for the [ib] harT communication port only:
• The PointWatch Carbon Dioxide Infrared Gas Detector model PIRECL shall be powered from a Safety Isolating Transformer
according to IEC60742 or IEC61588.
• The maximum cable distance between the HART Communicator and the PIRECL Infrared Carbon Dioxide Gas Detector
is 610 meters.
IEC Standards:
IEC 60079-0: 2007
IEC 60079-1: 2007-04
IEC 60079-11: 2006
IEC 60079-7: 2006-07
IEC 60529, 2.1 Edition with Corr. 1
(2003-01 + 2 (2007-10)
WarnInG
Always ensure that the detector/junction box hazardous (classified) location ratings are applicable for the intended use.
