f-4 95-8676 2.1
Device Status (read only)
This area of memory holds real time status information.
eclipse Status Information
Description address Value
General Status Bits 40201 Bit Values (See below)
Fault Status Bits 40202 Bit Values (See below)
Gas Level in %/vol
40203 Float LSW
40204 Float MSW
Calibration Step 40205 See Codes
Active Sensor Signal
40206 Float LSW
40207 Float MSW
Reference Sensor Signal
40208 Float LSW
40209 Float MSW
Sensor Ratio
40210 Float LSW
40211 Float MSW
Sensor Absorption
40212 Float LSW
40213 Float MSW
Temperature (°C)
40214 Float LSW
40215 Float MSW
Hour Meter
40216 Unsigned Long LSW
40217 Unsigned Long MSW
Max Temperature
40218 Float LSW
40219 Float MSW
Max Temp Hour
40220 Unsigned Long LSW
40221 Unsigned Long MSW
Max Temp (Since Reset)
40222 Float LSW
40223 Float MSW
Max Temp Hour (Since Reset)
40224 Unsigned Long LSW
40225 Unsigned Long MSW
Ram Error Code 40226 Unsigned Integer
Volume in %/vol
(Current Gas Type)
40227 Float LSW
40228 Float MSW
