IGP for Dot Matrix Printers
User Guide
46
Step 1.
Find the desired dot pattern from the two dot pattern columns. For example, use the dot
pattern from Figure 16. It is located in the right-hand column (it's the one inside the oval).
Step 2.
Look to the right of the dot pattern and determine the number for this particular dot
pattern. In the Figure we have provided the ASCII, Hexadecimal, and Decimal
equivalent. Whatever code you use, this number becomes the dot-pattern designator.
Step 3.
Send the Enter Plot Mode escape sequence followed by the dot-pattern designator
(ASCII = u), like this:
ESC
[ < 3 h u
1B 5B 3C 33 68 75
The desired dot pattern will print one time.
Repeating a Pattern
To repeat a dot pattern, add the desired number of repetitions after the dot-pattern designator.
When no repetitions are designated, the printer defaults to 1 and the dot pattern will be printed 1
time. For repetitions of 15 or fewer, the ASCII codes used to designate the number of repetitions
begin with S p (0) and continue through to the / (15).
In the example that follows the table, we show the sequence of actions required to compose an
ASCII data code.
Repetitions
ASCII
Multiples
ASCII
1—15
Value
Of 16
Value
0 Sp 00 0
1
!
16 x 1 = 16
1
2
“
16 x 2 = 32
2
3
#
16 x 3 = 48
3
4
$
16 x 4 = 64
4
5
%
16 x 5 = 80
5
6
&
16 x 6 = 96
6
7
'
16 x 7 = 112
7
8
(
16 x 8 = 128
8
9
)
16 x 9 = 144
9
10
*
16 x 10 = 160
:
11
+
16 x 11 = 176
;
12
,
16 x 12 = 192
<
13
–
16 x 13 = 208
=
14
.
16 x 14 = 224
>
15
/
16 x 15 = 240
?
Figure 17 – Repetition Conversion Table
