1 - 18 System Map: Bottom View - Model B
Quick Start Guide
1
System Map: Bottom View - Model B
Figure 1 - 9
Bottom View
(Model B
Computers)
1.
Battery
2.
Component Bay
Cover
3.
Vent/Fan Intake/
Outlet
4.
Subwoofer
2
3
1
3
3
Battery Information
Always completely dis-
charge, then fully charge, a
new battery before using it.
Completely discharge and
charge the battery at least
once every 30 days or after
about 20 partial discharges.
See
“Battery Information”
on page 3 - 10
for full in-
structions.
CPU
The CPU is not a user serviceable part.
Overheating
To prevent your computer from overheating make sure nothing blocks the Vent/Fan Intake
while the computer is in use.
3
3
3
4
