IT3000-AB
1/4” Ultra-Lok Tool
Production tools will experience wear of specific parts. Preventative maintenance, including
regular cleaning and lubrication, will reduce the replacement frequency of these parts. To
maximize life, use synthetic gel lubricant containing Teflon. See (pages 23-28) for tool
maintenance. When repairing tools, threaded fasteners should be secured using a small
amount of Loctite, Blue - Medium strength being careful to apply sparingly.
Note
–Please have tool model and serial #’s available when calling the factory for
service or assistance. Contact BAND-IT-IDEX customer service, 800-525-0758.
Part numbers are subject to change.
Part #
Replacement Parts
Description
Quantity per
Tool
I14687 Knife 1
I13887 Knife pin 1
I17687 Knife mounting screws 2
I14787 Blade 1
I13987 Blade pin 1
I30187 Tension block 1
I30190 Tension Block Assembly (Includes I30187,
I10388, I10888, and 2 A38487) 1
I24199 Flip Cover Assembly (Includes assembled flip
cover and 2 quick release pins) 1
I16387 Lubricant (synthetic gel lubricant containing
Teflon)
Maintenance
