Industrial Wireless Serial Device Server Series
SW550xC User Manual V 1.0
80
Combination 2: AW5500/AW5500C + SW550X/SW550XC:
When an AW5500 is selected with a SW550X, Serial Manager will instruct them to pair up
using the WPS (Wi-Fi Protected Setup) standard using the WPS PBC (Push-Button
Connection)
. However, since AW5500 only supports the “Configured” mode of WPS, the
following wireless settings need to set manually before you can proceed:
AW5500/AW5500C:
Table 5.7
Operation Mode
Regular AP
Basic Settings
SSID
User Define
Wireless Mode
User Define
WDS Settings
Authentication
WPA-PSK or WPA2-PSK
Encryption
TKIP or AES*
Passphrase
User Define
*Note that TKIP is not covered in the 802.11n standard and the wireless rate would be limited
to 54Mbps.
SW550X/SW550XC
Be aware if the SW550X has been configured previously. It needs to have the default settings
below in order for WPS to work. You can configure manually or reset SW550X back to default
using the Web UI or the physical reset to default button. Overview of the settings that will be
applied automatically:
Table 5.8
Basic Settings
Topology
Infrastructure
Wireless Mode
Auto
SSID
Matches AW550
Wireless Mode
Matches AW550
Authentication
Matches AW550
Encryption
Matches AW550
Passphrase
Matches AW550
